7. Connection Procedure
44
7.
onfirm that correct data are written to the I/O memory of the PLC by using the
1.4. Checking the Receive Data
C
CX-Programmer.
1
Select Edit - Memory from the
PLC Menu of the CX-Programmer.
2
PLC
layed.
Double-click CIO in the
Memory Window that is disp
(PLC Memory Window)
3
Enter 5500 in the Start Address
Field of the displayed CIO Dialog
Box.
Confirm that the start address was
changed to CIO 5500.
To Next Page
