Omron SYSMAC CJ1W-SCU41-V1 User Manual

536
E5ZE Temperature Controller Write Protocol Appendix I
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Output Value Change Rate Limit (Sequence No. 167 (Hex
00A7))
Writes the output value change rate limits that restrict the rates of change in the control value output.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0022 (0034 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Output value lower limit
(4 digits BCD)
0000 to 1000
+3 Channel 0
Output value upper limit
(4 digits BCD)
0000 to 1000
+4 Channel 0
Cooling output value lower limit
(4 digits BCD)
0000 to 1000
+5 Channel 0
Cooling output value upper limit
(4 digits BCD)
0000 to 1000
•
•
•
+32 Channel 7
Cooling output value lower limit
(4 digits BCD)
0000 to 1000
+33 Channel 7
Cooling output value upper limit
(4 digits BCD)
0000 to 1000
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+5
+6
+7
+8
+9
(Undefined) Unit No.
Output change rate limit
Output change rate limit
Channel 0
Channel 1
Output change rate limit
Channel 2
Output change rate limit
Channel 3
Output change rate limit
Channel 4
Output change rate limit
Channel 5
Output change rate limit
Channel 6
Output change rate limit
Channel 7
