Omron SYSMAC CJ1W-SCU41-V1 User Manual

537
E5ZE Temperature Controller Write Protocol Appendix I
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Save Settings (Sequence No. 168 (Hex 00A8))
Saves the settings.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Initialize Settings (Sequence No. 169 (Hex 00A9))
Initializes all the settings to the factory defaults.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
000A (0010 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Output change rate limit
(4 digits BCD)
0000 to 1000
+3 Channel 1
Output change rate limit
(4 digits BCD)
0000 to 1000
+4 Channel 2
Output change rate limit
(4 digits BCD)
0000 to 1000
•
•
•
+8 Channel 6
Output change rate limit
(4 digits BCD)
0000 to 1000
+9 Channel 7
Output change rate limit
(4 digits BCD)
0000 to 1000
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
