3Z4L Laser Micrometer Protocol Appendix N
Receive Data Word Allocation (4th Operand of PMCR(260))
First word of send
data
Number of receive data words
+0
+1
+2
+3
+4
+5
+6
+7
+8
+9
+10
+11
+12
+13
+14
+15
+16
+17
+18
+19
+20
+21
+22
+23
+24
+25
+26
+27
+28
+29
(Undefined)
(Undefined) Integer portion
Sign (Undefined)
Decimal portion
Decimal portion
(Undefined) Integer portion
Sign (Undefined)
Decimal portion
(Undefined) Integer portion
Sign (Undefined)
Decimal portion
(Undefined) Integer portion
Decimal portion
Sign (Undefined)
(Undefined) Integer portion
Decimal portion
Sign (Undefined)
(Undefined) Integer portion
Decimal portion
Sign (Undefined)
(Undefined) Integer portion
Decimal portion
Sign (Undefined)
(Undefined) Integer portion
Sign (Undefined)
(Undefined)
Program number (P)
Segment number (SG)
Measurement interval number (M)
Lower limit value (LL)
Upper limit value (LH)
Multistep selection limit value (L1)
Multistep selection limit value (L2)
Multistep selection limit value (L3)
Multistep selection limit value (L4)
Multistep selection limit value (L5)
Multistep selection limit value (L6)
+30
+31
+32
+33
+34
+35
+36
+37
+38
+39
+40
+41
+42
+43
+44
+45
(Undefined) Integer portion
Sign (Undefined)
(Undefined)
(Undefined)
Decimal portion
(Undefined) Integer portion
Sign (Undefined)
(Undefined)
(Undefined)
(Undefined)
Decimal portion
(PRT)
(SMP)
(Undefined)
Reference value (REF)
Analog output scale number (SCL)
Offset classification (OF)
Offset value (LH)
Data output condition (PR)
Sample measurement classification
Statistical processing calculation classification
Scheduled output timer
Sample measurement pulse
