Omron SYSMAC CJ1W-SCU41-V1

649
3Z4L Laser Micrometer Protocol Appendix N
Note This sequence cannot be used to request the lower limit (EL), error upper limit (EH), error exclusion
counter (CNT) of the error data exclusion function (centerless grinder function).
Offset Contents (data format) Data
+0 Number of receive data
words (4 digits Hex)
002E (0046 decimal) (fixed)
+1 Program number
(1 digit BCD)
0 to 9
+2 to +4 Segment number
(ASCII 6 characters)
Combination of 31(‘1’) to 36(‘6’), 20(‘ ’)
+5 Measurement interval num-
ber (1 digit BCD)
1 to 4
+6 Lower limit value (Decimal
portion)
(4 digits BCD)
0000 to 9999
+7 Lower limit value (Integer
portion)
(3 digits BCD)
000 to 999
+8 Lower limit value (Sign)
(BIN)
If +: 0
If – : F
+9 to
+11
Upper limit value Same as lower limit values
+12 to
+14
Multistep selection limit
value (L1)
Same as lower limit values
+15 to
+17
Multistep selection limit
value (L2)
Same as lower limit values
+18 to
+20
Multistep selection limit
value (L3)
Same as lower limit values
+21 to
+23
Multistep selection limit
value (L4)
Same as lower limit values
+24 to
+26
Multistep selection limit
value (L5)
Same as lower limit values
+27 to
+29
Multistep selection limit
value (L6)
Same as lower limit values
+30 to
+32
Reference value Same as lower limit values
+33 Analog output scale number
(1 digit BCD)
1 to 3
+34 to
+35
Offset classification (ASCII 3
characters)
4F4620 (“OF”), 4F4D20 (“OM”)
+36 to
+38
Offset value Same as lower limit values
+39 Data output condition
(1 digit BCD)
0 to 6
+40 Scheduled output timer
(3 digits BCD)
000 to 999
+41 Sample measurement pulse
(3 digits BCD)
000 to 999
+42 to
+43
Sample measurement clas-
sification
(ASCII 3 characters)
415647 (“AVG”), 4D4158 (“MAX”)
4D494E (“MIN”), 524E47 (“RNG”)
+44 to
+45
Statistical processing calcu-
lation classification (ASCII 3
characters)
535420 (“ST”), 4E5354 (“NST”)
4 5 6 7
0 1 2 3
F 0 0 0
+6
+7
+8
Example –123.4567
