Omron Sysmac NJ-series Connection Guide

6
．
EtherNet/IP Settings
9
6. EtherNet/IP Settings
This section describes the setting contents of parameters, global variables, tag sets, and tag
data link table that are all defined in this document.
6.1. Parameters
The parameters that are set in this document are shown below.
6.1.1. Communication Settings of Personal Computer
The parameters for Sensor Controller are set using Ethernet communications with Personal
Computer for settings.
The parameters required for connecting Personal computer for setting and Sensor Controller
using Ethernet communications are shown below.
Item Personal computer for setting Sensor Controller
IP address 192.168.250.100 192.168.250.50 (Default)
Subnet mask 255.255.255.0 255.255.255.0
6.1.2. EtherNet/IP Communications Settings
The parameters required for connecting Controller to Sensor Controller via EtherNet/IP are
shown below.
Item Controller Sensor Controller Remarks
IP address
192.168.250.1
192.168.250.50 (Default)
Using Sysmac Studio.
Subnet mask 255.255.255.0 255.255.255.0 Using Sysmac Studio.
Fieldbus - EtherNet/IP Using Sysmac Studio.
