EtherNet/IP Connection Procedure
34
17
Click the + Button.
A row for new entry is added.
Click the Down Arrow Button of
the entry cell in the Variable to
be refreshed Column (the left
side of the figure).
The variables set in the previous
steps are displayed.
Select EIPOutput.
EIPOutput is added.
*Since the data types are
displayed automatically, you do
not need to set them.
18
In the same way as step 17, add
all the variables set in the
previous steps to the Variable to
be refreshed Column (the left
side of the figure).
*Since the data types are
displayed automatically, you do
not need to set them.
