Omron V600 Series Operation Manual

3-3SectionCommand Format
32
• One character of data occupies exclusively one byte of DC memory (one
address) in either ASCII code.
ASCII Code Specification Example
WTA10010OMRON
∗
Header
For 1 to 1 procedure
Command
ASCII code specification
R/W Head no.
Start address
W rite data
0011
0012
0013
0010
0014
4 F ”O”
4 D ”M”
5 2 ”R”
4 F ”O”
4 E ”N”
Data Carrier Memory Address
@ Unit No. W T A 1 0 0 1 0 O M R O N
∗
FCS
For 1 to N Procedure
Write data
Start address
Command
Header
ASCII code specification
R/W Head no.
00 to 15
Note Refer to Appendix B for the ASCII code.
Hexadecimal Code Specification
• Character 1 is handled as hexadecimal numerical data. Thus, only characters
0 to F can be accepted.
• Data character 2 occupies exclusively one byte (one address) of DC memory
as is, and consequently it is extremely important to ensure that all write com -
mands are specified in two-character units (even number). If an odd number of
data characters are specified by mistake, this causes an error.

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
