4-1 Using Monitor Unit (V600-P01)
The Monitor Unit is a monitoring tool mounted on the ID Controller . It can be used
during system startup to check communications with the DC, to read or write
data to the DC, and to read any error messages.
4-1-1 Monitor Unit Functions
The Monitor Unit has the following functions which are executed in the MON-
ITOR Mode.
TEST: test function MONIT OR mode Read
Write
Auto read
Auto write
Error message
display
Clear error
Display error
statistics
Clear error
statistics
ERR: Error log
display
RUN mode
READ: Read
operation
JOB: The job
WRITE1: Stepped
write operation
WRITE2: Continu -
ous write operation
Repeats execution of communications
between the R/W Head and the DC.
Reads out new information in stored error
data sequentially .
Clears error data stored in ID Controller .
Displays subtotals of number of errors by
type.
Clears error statistics.
The date (year, month, day) to start
keeping statistics can be specified.
In the RUN Mode, Monitor Unit Key
input cannot be accepted.
Sets head no. and page no.
Reads data in any desired DC address.
W rites data into any desired DC address
one byte at a time.
W rites the same data to any desired DC
memory areas.
Note Remove the Monitor Unit before starting operations.

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
