Omron V600 Series Operation Manual

6-2SectionDiagnostic Functions
96
When an abnormality occurs in communications between the ID Controller and
the host computer or a R/W Head, the ERROR indicator lights. Up to 30 files of
abnormality data are stored, and if this number is exceeded, old abnormality
data
is erased from the beginning to make room for the new data. If the Monitor
Unit is used, apart from reading the details of these errors, it is also possible to
get the subtotals of the number of error occurrences by type.
6-2-2 Indications During Operation and Output Conditions
Condition Parameter Details Indicators Error
POWER HEAD1 HEAD2 ERROR STOP
Normal
Operation
Waiting for data
transmission or
reception
--- Lit Not lit Not lit Not lit Not lit OFF
Data
transmission or
reception in
progress
In communication with
R/W Head 1
Lit Lit Not lit Not lit Not lit OFF
In communication with
R/W Head 2
Lit Not lit Lit Not lit Not lit OFF
Operation
termination
b lit
CPU
abnormality
System program
abnormality
Lit Not lit Not lit Lit Lit ON
abnormality
Memory
abnormality
System memory
abnormality
Lit Not lit Not lit Lit Lit ON
Continuation
abnormality
Communications
abnormality
Abnormality in
communications with
host computer or PC
Abnormality in
communications with
R/W Head
Lit Not lit Not lit Lit Not lit OFF
Emergency
Stop
Reset
processing
Reset input is turned
on
Lit Not lit Not lit Not lit Lit OFF
Operation Continuation
Abnormality

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
