SECTION 5
V600 Commands
RFID System
User’s Manual
SECTION 5
Communications
1:N Protocol
First Frame
All Other Frames
Data designation Specifies the code format for sending the write data to the Tag.
“A”: ASCII
“H”: Hexadecimal
Antenna designation Specifies the Antenna with which to communicate.
“1”: Antenna 1
“2”: Antenna 2
Write area start address Specifies the start address of the area from which data is to be written in 4-digit
Setting range: 0000
H to FFFFH
Write data Specified the data to be written to the Tag.
Number of characters: 1 to 257
Delimiter CR: Indicates the end of the frame when there is another frame.
Terminator *CR: Indicates the end of the frame when there is not another frame.
Write data Specified the data to be written to the Tag.
Number of characters: 0 to 265
Delimiter CR: Indicates the end of the frame when there is another frame.
Terminator *CR: Indicates the end of the frame when there is not another frame.
Command
XW
A/H 1/2
211 4
1 or 2
* CR
n
2
FCS
3
@
Command
code
Terminator
Antenna
designation
Controller No.
×
Data
desig-
nation
Write data
Write area start address
×
×
×
×
×
×
×
×
×
×
×
Write data
1 or 2
* CR
n
2
FCS
3
@
Terminator
Controller No.
×
××
×
×
×
×
××
×
×
×
To Next Page
