205
RFID System
User’s Manual
SECTION 5
V600 Commands
SECTION 5
Communications
AUTO COPY (AP)
When the ID Controller receives the AUTO COPY command, it waits for Tags to approach and then
reads data from the memory of the Tag using one Antenna and writes it to the memory of the Tag in the
other Antenna's communications area. An error response (end code 76: copy error) will be returned if
there is no Tag at the copy destination.
This command cannot be used with the V680-CA5D01-V2.
1:1 Protocol
Data designation Always “H”.
Antenna designation Specifies the Antenna with which to communicate.
“1”: Reads from Antenna 1 and writes to Antenna 2.
“2”: Reads from Antenna 2 and writes to Antenna 1.
Read area start address Specifies the start address of the area in the Tag from which data is to be read from in 4-digit
hexadecimal.
Setting range: 0000
H to FFFFH
No. of bytes to copy Specifies the number of bytes of data to copy in 4-digit hexadecimal.
Setting range: 0001
H to 0800H
Destination start address Specifies the start address of the area in the Tag to which data is to be written in 4-digit
hexadecimal.
Setting range: 0000
H to FFFFH
End code Indicates the execution result for the command.
“00” indicates a normal end.
Refer to List of End Codes for information on other end codes.
p. 235
AP
H
211 4
4
2
* CR
1/2
Destination start
address
4
Command
code
Terminator
Antenna
designation
×
Read area start
address
No. of bytes to copy
Data
desig-
nation
××
×
×
×
×
××
×
×
×
Command
Response
AP
00
22
2
* CR
Command
code
Terminator
End code
To Next Page
