SECTION 5
V600 Commands
RFID System
User’s Manual
SECTION 5
Communications
1:N Protocol
Data designation Always “H”.
Antenna designation Specifies the Antenna with which to communicate.
“1”: Reads from Antenna 1 and writes to Antenna 2.
“2”: Reads from Antenna 2 and writes to Antenna 1.
Read area start address Specifies the start address of the area in the Tag from which data is to be read from in 4-digit
hexadecimal.
Setting range: 0000
H to FFFFH
No. of bytes to copy Specifies the number of bytes of data to copy in 4-digit hexadecimal.
Setting range: 0001
H to 0800H
Destination start address Specifies the start address of the area in the Tag to which data is to be written in 4-digit
hexadecimal.
Setting range: 0000
H to FFFFH
End code Indicates the execution result for the command.
“00” indicates a normal end.
Refer to List of End Codes for information on other end codes.
p. 235
Command
code
Controller No.
AP
H
2
1
1
4
4
1/2
Destination start address
4
2
*
CR
2
FCS
3
@
Terminator
Antenna
designation
×
Read area start
address
No. of bytes to copy
Data
desig-
nation
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
Command
Response
AP
00
22
2
* CR
2
FCS
3
@
Command
code
Terminator
End code
Controller No.
×
×
×
×
To Next Page
