RFID System
User’s Manual
SECTION 5
V600 Commands
SECTION 5
Communications
1:N Protocol
Data designation Specifies the code format when sending the Tag write data.
“A”: ASCII
“H”: Hexadecimal
Antenna designation Specifies the Antenna with which to communicate.
“1”: Antenna 1
“2”: Antenna 2
Write area start address Specifies the start address of the area in the Tag to which data is to be written in 4-digit
hexadecimal.
Setting range: 0000
H to FFFFH
Write data Specified the data to be written to the Tag.
Up to 256 bytes can be written with one command.
• ASCII: 256 bytes (256 characters)
• Hexadecimal: 256 bytes (512 characters)
Note: When hexadecimal is designated, set two characters for each byte.
End code Indicates the execution result for the command.
“74”: Polling command received
The only error codes that may be returned here are 74 and communications errors with the host
device.
Refer to List of End Codes for information on other end codes.
p. 235
PW
A/H 1/2
211 4
2
* CR
n 2
FCS
3
@
Command
code
Terminator
Antenna
designation
Controller No.
×
Write area start
address
Write data
Data
desig-
nation
×××
×× ××
××
××
Command
Response
PW
00
22
2
* CR
2
FCS
3
@
Command
code
Terminator
End code
Controller No.
×
×
×
×
To Next Page
