RFID System
User’s Manual
SECTION 7
Specifications and Dimensions
SECTION 7
Appendices
255
Dimensions
(Unit: mm)
95 ±0.2
80 ±0.2
Two, M 4
95
105
80
5
5
Two, 4.5 dia.
(Mounting hole)
90
65
80
1817.5
7.5
Mounting hole dimensions
