254
SECTION 7
Specifications and Dimensions
RFID System
User’s Manual
SECTION 7
Appendices
Output Section
● Relay
COM
IN
IN
RUN
BUSY/OUT3
ERROR/
OUT4
OUT1
OUT2
COM_O
● PLC Output Unit
(C200H-ID212,
C500-ID218, etc.)
24-VDC
power
supply
ID Controller output section
Internal circuit
Internal circuit
Internal circuit
Internal circuit
Internal circuit
Internal circuit
Internal circuit
+
