SECTION 7
Characteristics According to Operating Conditions
RFID System
User’s Manual
SECTION 7
Appendices
V680-HA63A, V680-HS@@, V680-D1KP@@, V680-H01, V680-D1KP58HT
Conditions
No. of bytes
processed
(byte)
9,600 bps
(ms)
19,200 bps
(ms)
38,400 bps
(ms)
115,200 bps
(ms)
Read
Communications speed
Normal mode
100 302 231 196 173
256 684 524 443 389
512 1,311 1,003 850 747
1,000 2,501 1,921 1,621 1,431
Write
With verification
Communications speed
Normal mode
100 409 338 303 280
256 916 756 675 621
512 1,748 1,440 1,287 1184
1,000 3,328 2,748 2,448 2,258
Write
Without verification
Communications speed
Normal mode
100 377 306 271 248
256 837 677 596 542
512 1,592 1,284 1,131 1,028
1,000
3,026 2,446 2,146 1,956
Read (See note 1.)
Communications speed
High-speed mode
100 270 199 164 141
256 605 445 364 310
512 1,155 847 694 591
1,000
2,199 1,619 1,319 1,129
Write (See note 1.)
With verification
Communications speed
High-speed mode
100 372 301 266 243
256 832 672 591 537
512 1,587 1,279 1,126 1,023
1,000 3,021 2,441 2,141 1,951
Write (See note 1.)
Without verification
Communications speed
High-speed mode
100 338 267 232 209
256 751 591 510 456
512 1,429 1,121 968 865
1,000
2,717 2,137 1,837 1,647
Note 1. The V680-H01 Antenna cannot be used in high-speed mode because it will result in an error.
When using multi-access or FIFO communications options, normal-mode communications speed will be used regardless
of the high-speed mode setting.
2. TAT data is for a V680-CA5D01/02-V2 ID Controller with the following communications settings: 8-bit data length, 1 stop
bit, and odd parity. Data was sent continuously without breaks between characters.
3. The number of bytes for TAT data is when the code designation is set to ASCII.
