Omron V680-CA5D01-V2 User Manual

RFID System
User’s Manual
SECTION 7
Characteristics According to Operating Conditions
SECTION 7
Appendices
261
V680-HA63B, V680-HS@@, V680-D2KF@@
Conditions
No. of bytes
processed
(byte)
9,600 bps
(ms)
19,200 bps
(ms)
38,400 bps
(ms)
115,200 bps
(ms)
Read
Communications
speed
Normal mode
100 291 220 185 162
256 658 498 417 363
512 1,259 951 798 695
1,000 2,400 1,820 1,520 1,330
2,000 4,760 3,590 3,020 2,620
Write
With verification
Communications
speed
Normal mode
100 430 359 324 301
256 984 824 743 689
512 1,892 1,584 1,431 1,328
1,000 3,619 3,039 2,739 2,549
2,000 7,139 4,849 5,439 5,039
Write
Without verification
Communications
speed
Normal mode
100 310 239 204 181
256 677 517 436 382
512 1,278 970 817 714
1,000 2,419 1,839 1,539 1,349
2,000 4,779 2,449 3,039 2,639
Read (See note. 1)
Communications
speed
High-speed mode
100 261 190 155 132
256 581 421 340 286
512 1,105 797 644 541
1,000 2,100 1,520 1,220 1,030
2,000 4,160 1,830 2,420 2,020
Write (See note 1.)
With verification
Communications
speed
High-speed mode
100 360 289 254 231
256 805 645 564 510
512 1,534 1,226 1,073 970
1,000 2,919 2,339 2,039 1,849
2,000 5,779 3,449 4,039 3,639
Write (See note 1.)
Without verification
Communications
speed
High-speed mode
100 272 201 166 143
256 592 432 351 297
512 1,116 808 655 552
1,000 2,111 1,531 1,231 1,041
2,000 4,171 1,841 2,431 2,031
Note 1. When using multi-access or FIFO communications options, normal-mode communications speed will be used regardless
of the high-speed mode setting.
2. TAT data is for a V680-CA5D01/02-V2 ID Controller with the following communications settings: 8-bit data length, 1 stop
bit, and odd parity. Data was sent continuously without breaks between characters.
3. The number of bytes for TAT data is when the code designation is set to ASCII.
