262
SECTION 7
Characteristics According to Operating Conditions
RFID System
User’s Manual
SECTION 7
Appendices
V680-HA63B, V680-HS@@, V680-D8KF@@, V680-D32KF@@
Conditions
No. of bytes
processed
(byte)
9,600 bps
(ms)
19,200 bps
(ms)
38,400 bps
(ms)
115,200 bps
(ms)
Read
Communications
speed
Normal mode
100 301 230 195 172
256 683 523 442 388
512 1,310 1,002 849 746
1,000 2,500 1,920 1,620 1,430
2,000 4,960 2,630 3,220 2,820
Write
With verification
Communications
speed
Normal mode
100 360 289 254 231
256 789 629 548 494
512 1,493 1,185 1,032 929
1,000 2,829 2,249 1,949 1,759
2,000 5,589 3,259 3,849 3,449
Write
Without verification
Communications
speed
Normal mode
100 321 250 215 192
256 703 543 462 408
512 1,330 1,022 869 766
1,000 2,520 1,940 1,640 1,450
2,000 4,980 2,650 3,240 2,840
Read (See note 1.)
Communications
speed
High-speed mode
100 246 175 140 117
256 550 390 309 255
512 1,049 741 588 485
1,000 1,995 1,415 1,115 925
2,000 3,955 1,625 2,215 1,815
Write (See note 1.)
With verification
Communications
speed
High-speed mode
100 292 221 186 163
256 643 483 402 348
512 1,219 911 758 655
1,000 2,311 1,731 1,431 1,241
2,000
4,571 2,241 2,831 2,431
Write (See note 1.)
Without verification
Communications
speed
High-speed mode
100 271 200 165 142
256 591 431 350 296
512 1,115 807 654 551
1,000 2,110 1,530 1,230 1,040
2,000
4,170 1,840 2,430 2,030
Note 1. When using multi-access or FIFO communications options, normal-mode communications speed will be used regardless
of the high-speed mode setting.
2. TAT data is for a V680-CA5D01/02-V2 ID Controller with the following communications settings: 8-bit data length, 1 stop
bit, and odd parity. Data was sent continuously without breaks between characters.
3. The number of bytes for TAT data is when the code designation is set to ASCII.
