SECTION 1
System Configuration
RFID System
User’s Manual
SECTION 1
Product Overview
• Using a V680-H01 Antenna
The V680-H01 Antenna can be connected only to the V680-CA5D01-V2 ID Controller. It cannot be used with the V680-
CA5D02-V2 ID Controller
ID Controller
V680-CA5D01-V2
Tag
Pallet or other object
RS-422/RS-485 RS-422/RS-485 RS-422/RS-485
Tag
Pallet or other object
Programmable Controller
Personal computer
(PLC)
Antennas
V680-H01
RS-422/RS-485
