RFID System
User’s Manual
SECTION 2
Connection and Wiring
SECTION 2
Installation, Connections, and Wiring
Checking Installation
Use the following procedure to confirm that the driver has been correctly installed.
1. Connect the ID Controller to the computer via USB.
2. Select Settings - Control Panel - System from the Windows Start Menu.
3. Click the Device Manager Button on the Hardware Tab Page.
4. Select Ports (COM & LPT) and check that OMRON RFID USB COM is displayed.
If the driver is correctly installed the property window for the V680-CA5D@@-V2 will be as follows:
Communications with the ID Controller can be performed with the COM number displayed in parentheses after OMRON RFID
USB COM.
