48
SECTION 2
Connection and Wiring
RFID System
User’s Manual
SECTION 2
Installation, Connections, and Wiring
Windows XP
1. Turn ON the power to the computer and start Windows XP.
2. Connect the ID Controller to the computer via USB.
Refer to USB Port for details on the connection method.
p. 42
Wait for the following dialog box to be displayed.
3. When the following dialog box is displayed, select Install from a list or specific location (Advanced) and
click the Next Button.
4. Click the Browse Button and select the folder in which the downloaded V680-CA5D_100.inf file is to be
saved. Then click the Next Button.
To Next Page
