77
RFID System
User’s Manual
SECTION 3
Trial Operation
SECTION 3
Preparations for Communications
Communications Test with Host Device
The TEST command is used to perform a communications test of the communications between the
Controller and host device. This test enables the cable connections and processing operation of com-
munications to be checked before the trial operation of the whole system.
1. Create a simple communications program on the host device and send the TEST command (TS).
If the communications line is normal, the Controller will return the data it received.
Refer TEST Command (TS) for details on the TEST command.
p. 166
 Example
Sending Message Data “OMRON” from Controller No. 2.
1) Send
2) Receive
Host device TEST command
TSXXX...............XXX*
Test data: 262 characters max.
Host device response
TS0000XXX...............XXX*
Test data response
Command
Command
code
TS
MR
ON
2
2
*
CR
Terminator
24
FCS
0@
2
Controller No.
2
O
5
Message data
02
1
1
Response
TS
MR
ON
2
2
*
CR24
FCS
0@
2
2
O
5
Message data
02
1
1
00
End code
2
0
1
0
1
Command
code
Terminator
Resend
flag
Controller No.
Fixed
value
