113
Register Number Allocations in Detail Chapter 7-7
Status Signal (Register 0020 Hex)
Fault Status (Register 0021 Hex)
Note When a fault results, the corresponding bit will be set to 1.
Data Link Status (Register 0022 Hex)
Input Terminal Status (Register 002B Hex)
Bit No. Function
0 During RUN (1: During RUN)
1 Forward/reverse operation (1: Reverse operation)
2 Inverter ready (1: Ready)
3 Fault (1: Fault)
4 Data setting error (1: Error)
5 Multi-function output (1: ON)
6 to 15 Not used.
Bit No. Function Bit No. Function
0 OC 8 F_
1 OV 9 OL1
2 OL2 10 OL3
3 OH 11 Not used.
4 Not used. 12 UV1
5 Not used. 13 GF
6 Not used. 14 CE
7 EF_, STP 15 Not used.
Bit No. Function
0 Data writing (1: Writing)
1 to 2 Not used.
3 Upper and lower limit error (1: Error): Outside set range
4 Verify error (1: Error): Same as OPE_.
5 to 15 Not used.
Bit No. Function
0 Forward/stop terminal (S1) (1: ON)
1 Multi-function input terminal 1 (S2) (1: ON)
2 Multi-function input terminal 2 (S3) (1: ON)
3 Multi-function input terminal 3 (S1) (4: ON)
4 Multi-function input terminal 4 (S5) (1: ON)
5 to 15 Not used.
