Multi-function I/0 Chapter 5-9
5-9 Multi-function I/0
5-9-1 Multi-function Input
The J7AZ incorporates four multi-function input terminals (S2 through S5).
Inputs into these terminals have a variety of functions according to the
application.
Multi-function Input (n36 through n39)
Note Do not set values outside the above setting ranges.
n36 Multi-function Input 1 (S2) Changes during
operation
No
Setting
range
2 to 8, 10 to 22
(see note)
Unit of
setting
1 Default setting 2
n37 Multi-function Input 2 (S3) Changes during
operation
No
Setting
range
0,2 to 8, 10 to 22
(see note)
Unit of
setting
1 Default setting 5
n38 Multi-function Input 3 (S4) Changes during
operation
No
Setting
range
2 to 8, 10 to 22
(see note)
Unit of
setting
1 Default setting 3
n39 Multi-function Input 4 (S5) Changes during
operation
No
Setting
range
2 to 8, 10 to 22, 34, 35
(see note)
Unit of
setting
1 Default setting 6
