18
Wiring Chapter 2-2
Single-phase 200-V AC Model
3-phase 400-V AC Model
Model
CIMR-J7AZ-
Terminal symbol Terminal
screw
Terminal
torque
(N•m)
Wire size
(mm
2
)
Re-
commended
wire size
(mm
2
)
Circuit
breaker
capacity
(A)
B0P1 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 5
B0P2 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 5
B0P4 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 10
B0P7 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5 3.5 20
2
B1P5 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5 5.5 20
2
Model
CIMR-J7AZ-
Terminal symbol Terminal
screw
Terminal
torque
(N•m)
Wire size
(mm
2
)
Re-
commended
wire size
(mm
2
)
Circuit
breaker
capacity
(A)
40P2 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5 2 5
40P4 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5 2 5
40P7 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5 2 5
41P5 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5 2 10
42P2 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M4 1.2 to 5.5 2 to 5.5 2 10
44P0 R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5 2 to 5.5 2 20
3.5
