Omron ZX Series Manual

13
ZX SERIESZX SERIES
Dimensions
Unit: mm (inch)
■
Sensor Heads (Diffuse Reflective)
■ Sensor Heads (Regular Reflective)
33
(1.30)
7
7
14.8 (0.58)
3.4
30.05
(1.18)
39 (1.53)
A ∗
32
3.5
7
7
24.05
26
(1.02)
46
(1.81)
3.5
L ∗
17
(0.67)
26±
0.1
32±
0.1
16.6
12.4
5
1.8
31.1
(1.22)
ZX-LD40
ZX-LD100
ZX-LD300
ZX-LD40L
ZX-LD100L
ZX-LD300L
Lens: 5 dia.
Lens: 8 dia.
Emitter axis
Receiver axis
Measurement
point
Reference
surface
Connector
∗ ZX-LD40L: L = 40 mm, A = 23°
ZX-LD10L: L = 100 mm, A = 11°
ZX-LD30L: L = 300 mm, A = 3.8°
Vinyl-insulated round cable, 5.1 dia.,
Standard: 500 mm
Range
indicators
Two 3.2-dia. mounting
holes
Mounting Holes
Two, M 3 h ol e s
15 dia.
47
55
(2.17)
46
(1.81)
30
32.7
(1.29)
4.75
4.75
45
(1.77)
35°
42.7
(1.68)
11
9.2
9.5
12.5
8.6
25
(0.98)
14
4.8
5-R2
47±
0.1
Two, M4 holes
20.7
(0.81)
ZX-LD30V
ZX-LD30VL
Mounting Holes
Vinyl-insulated round cable,
5.1 dia., Standard: 0.5 m
Connector
Light axis
Two, 4.5-dia.
mounting holes
Reference plain
Receiver
axis
Emitter
axis
Lens (10 dia.)
Measurement center
Lens (16 dia.)
15 dia.

Omron ZX Series Specifications

General

Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67
Output Type	NPN or PNP
Protection Circuit	Reverse polarity protection, short-circuit protection
Operating Temperature	-25 to 55°C (-13 to 131°F)
