Omron ZX Series Manual

14
ZX SERIESZX SERIES
■ Sensor Heads (Through-beam)
■ Amplifier Units
99
5
2.8
19
(0.75)
16
9±
0.1
Two, M3 holes
9±
0.1
Two, M3 holes
34
(1.34)
2.8
15 (0.59)
15 (0.59)
15 (0.59)
15 (0.59)
Vinyl-insulated round cable
(gray), 2.6 dia., Standard:
500 mm
Mounting Holes
Mounting Holes
Emitter side
Receiver side
Vinyl-insulated round cable (black),
2.6 dia., Standard: 500 mm
Connector
Connector
Light axis center
Laser ON indicator
Two, 3.2 dia.
Light axis center
Two, 3.2 dia.
ZX-LT001
ZX-LT005
14
20 ( 0.79)
22
2.8
14
10
2.8
14±
0.1
14±0.1
Two, M3 holes
42
(1.65)
20 ( 0.79)
20 ( 0.79)
25
(0.98)
20 ( 0.79)
Two, M3 holes
ZX-LT010
Vinyl-insulated round cable
(gray), 2.6 dia., Standard:
500 mm
Mounting Holes
Mounting Holes
Emitter side Receiver side
Vinyl-insulated round cable (black),
2.6 dia., Standard: 500 mm
Connector
Connector
Light axis center
Laser ON indicator
Two, 3.2 dia.
Light axis center
Two, 3.2 dia.
3
64.3
(2.53)
15.8
13 36.8
31.5
(1.24)
44
30
(1.18)
13.2
11.7
11.7
29
2.2
133
(5.24)
4.24.2
ZX-LDA11
ZX-LDA41
15.5 dia.
Vinyl-insulated round cable,
5.1 dia., Standard: 100 mm
Vinyl-insulated round cable, 5.2 dia.
(conductor cross-section: 0.09 mm
2
, insulator
diameter: 0.7 mm), Standard: 2 m

Omron ZX Series Specifications

General

Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67
Output Type	NPN or PNP
Protection Circuit	Reverse polarity protection, short-circuit protection
Operating Temperature	-25 to 55°C (-13 to 131°F)
