Onkyo DV CP704 User Manual

15
Controls & Connectors—Continued
N ASPECT/ZOOM button (41, 44)
This button is used to change the view mode. Press-
ing and holding it for a few seconds selects Zoom
mode.
O RESOLUTION button (39)
This button is used to set the video resolution of the
HDMI OUT, and to turn the HDMI OUT on or off.
P OPEN/CLOSE [ ] button (23, 24)
This button is used to open and close the disc tray.
Q DISC SKIP [+]/[–] button (23, 24)
This button is used to select the disc bays (i.e.,
rotate the disc tray) when loading or removing
discs, and to select discs for playback.
R SEARCH button (28, 29)
This button is used to search for titles, chapters,
tracks, and specific points in time.
S MEMORY button (36)
This button is used with the Memory Playback
function.
T REPEAT button (34)
This button is used to set the Repeat Playback func-
tions.
U A–B button (34)
This button is used to set the A–B Repeat Playback
function.
V CLR button (37, 47)
This button is used to cancel various functions.
W DISPLAY button (41)
This button is used to display information about the
current disc, title, chapter, or track, including the
elapsed time, remaining time, total time, and so on.
X ANGLE button (37)
This button is used to select different camera angles.
Y LAST MEMORY button (40)
This button is used with the Last Memory function.
Z Pause [ ] button (25, 30)
This button is used to pause playback. For DVDs,
pressing this button while playback is paused moves
the video forward one frame at a time.
a Next [ ] button (25, 27, 29, 32)
This button is used to select the next chapter or
track.
b Stop [ ] button (25)
This button is used to stop playback.
c Fast Forward [ ] button (30)
This button is used to start fast forward.
d ENTER button (43)
This button is used to start playback of the selected
title chapter, or track and to confirm settings.
e SETUP button (43)
This button is used to open and close the onscreen
setup menus.
f RETURN button (43)
This button is used to exit the onscreen setup
menus.
g CHAIN MODE button (33)
This button is used with the Chain mode function.

Onkyo DV CP704 Specifications

Operating Environment

Operating temperature	5° to 35° C (41° F to 95° F)

Power

Power supply (U.S. model)	120 V AC, 60 Hz
Power supply (Australian model)	100–240 V AC, 50/60 Hz
Power consumption	13 W
Power consumption in Standby mode (U.S. model)	0.35 W
Power consumption in Standby mode (Australian model)	0.35 W

Audio Specifications

Signal-to-noise ratio	95 dB
Audio dynamic range	95 dB
Total harmonic distortion	0.007% (1 kHz)
Wow and flutter	Below threshold of measurability

Video Outputs

Component video Y	1.0 V (p–p), 75 Ω, negative sync, RCA/phono x3
Component video PB/PR	0.7 V (p–p), 75 Ω
S VIDEO Y	0.7 V (p–p), 75 Ω, negative sync, 4-pin mini DIN x1
S VIDEO C	0.286 V (p–p), 75 Ω
Composite video	1.0 V (p–p), 75 Ω, negative sync, RCA/phono x1

Audio Outputs

Optical output	–22.5 dBm, optical connector x1
Coaxial output	0.5 V (p–p), 75 Ω, RCA/phono x1
Analog output	2.0 V (rms), 540 Ω, RCA/phono x2
HDMI output	19 pin connector

Weight and Dimensions

Weight	5.5 kg (12.1 lbs.)
Dimensions (W x H x D)	435 X 91 X 432 mm (17-1/8 X 3-9/16 X 17 ins.)
