Specifications
AMPLIFIER SECTION
Continuous Average Power output (FTC)
All channels: 110 watts per channel min. RMS at
8 ohms, 2 channels driven from 20
Hz to 20 kHz with no more than
0.08% total harmonic distortion.
145 watts min. RMS at 6 ohms, 2
channels driven from 1 kHz with
no more than 0.1% total harmonic
distortion.
Continuous Power output (DIN) 150 watts at 6 ohms
Maximum Power output (EIAJ) 180 watts at 6 ohms
Dynamic Power Output (Stereo) 2 × 280 watts at 3 ohms
2 × 220 watts at 4 ohms
2 × 140 watts at 8 ohms
Total Harmonic Distortion: 0.08% at rated power
0.08% at 1 Watt output
IM Distortion: 0.08% at rated power
0.08% at 1 Watt output
Damping Factor: 60 at 8 ohms
Input Sensitivity and Impedance
PHONO: 2.5 mV, 50 kohms
LINE (CD, TAPE, DVD,
VIDEO 1-5): 200 mV, 50 kohms
MULTICHANNEL INPUT
(FRONT L/C/R, SURROUND
L/R, SURROUND BACK L/R): 200 mV, 50 kohms
(SUBWOOFER): 36 mV, 50 kohms
COAXIAL 1, 2, 3 (DIGITAL): 0.5 Vp-p, 75 ohms
DVD, VIDEO 1, 2, 3, 4, 5: 1 Vp-p, 75 ohms
1 Vp-p, 75 ohms (Y)
0.28 Vp-p, 75 ohms (C)
COMPONENT VIDEO 1, 2: 1 Vp-p, 75 ohms (Y)
0.7 Vp-p, 75 ohms (PB, PR)
Output Level and Impedance
Rec out (TAPE, VIDEO 1, 2):
200 mV, 470 ohms
Pre out: 1 V, 470 ohms
ZONE 2 OUT: 100mV, 470 ohms
VIDEO (VIDEO 1, 2, MONITOR
OUT, ZONE 2 OUT): 1 Vp-p, 75 ohms
1 Vp-p, 75 ohms (Y)
0.28 p-p, 75 ohms (C)
COMPONENT VIDEO OUT: 1 Vp-p, 75 ohms (Y)
0.7 Vp-p, 75 ohms (PB, PR)
Phono Overload:
120 mV RMS at 1 kHz, 0.5% T.H.D.
Frequency Response: 10 Hz to 100 kHz : +1/–3 dB
(CD in Direct mode)
RIAA Deviation: 20 Hz to 20 kHz : ±0.8 dB
Tone Control
Bass: ±10 dB at 50 Hz
Treble: ±10 dB at 20,000 Hz
Signal-to-Noise Ratio (Stereo)
Phono: 80 dB (IHF A, 5 mV input)
CD/Tape: 110 dB (IHF A, 0.5 V input)
TUNER SECTION
FM
Tuning Range: 87.5 — 108.0 MHz (50 kHz steps)
Usable Sensitivity
Mono: 11.2 dBf, 1.0 µV (75 ohms IHF)
0.9 µV (75 ohms DIN)
Stereo: 17.2 dBf, 2.0 µV (75 ohms IHF)
23 µV (75 ohms DIN)
50 dB Quieting Sensitivity
Mono: 17.2 dBf, 2.0 µV (75 ohms)
Stereo: 37.2 dBf, 20 µV (75 ohms)
Capture Ratio: 2.0 dB
Image Rejection Ratio 85 dB
IF Rejection Ratio: 90 dB
Signal-to-Noise Ratio
Mono: 76 dB
Stereo: 70 dB
Alternate Channel Attenuation: 55 dB
Selectivity: 50 dB (DIN)
AM Suppression Ratio: 50 dB
Total Harmonic Distortion
Mono: 0.2%
Stereo: 0.3%
Frequency Response: 30 Hz — 15 kHz, ±1.0 dB
Stereo Separation: 45 dB at 1 kHz
30 dB at 100 Hz — 10 kHz
AM
Tuning Range:
Other than world wide models: 522 to 1,611 kHz (9-kHz steps)
Worldwide models: 531 to 1,602 kHz (9-kHz steps)
530 to 1,710 kHz (10-kHz steps)
Usable Sensitivity: 30 µV
Image Rejection Ratio: 40 dB
IF Rejection Ratio: 40 dB
Signal-to-Noise Ratio: 40 dB
Total Harmonic Distortion: 0.7%
GENERAL
Power Supply: AC 230-240 V, 50 Hz
(European & Australian models)
AC 220-230 V, 50/60 Hz
(some Asian models)
AC 220-230 and 120 V switchable,
50/60 Hz (Worldwide models)
Power Consumption: 630 W
Dimensions (W × H × D): 435 × 175 × 459 mm
Weight: 17.9 kg
Specifications and features are subject to change without notice.
