Onkyo PHA-1045

20
Connecting Other Components
About Connections
Cables and Jacks
No connecting cables are included with the stereo receiver.
Connecting a Subwoofer
The stereo receiver has a SUBWOOFER PRE OUT jack for connecting a powered subwoofer (i.e., a subwoofer with a
built-in amplifier).
Cable Jack Description
Analog audio cable
This cable carries analog audio.
Optical digital audio
cable
This cable carries digital audio.
COAXIAL digital audio
cable
This cable carries digital audio.
R
L
OPTICAL
COAXIAL
Stereo receiver
: Signal fl o w
P o w ered s u b w o o f er
LINE INPUT
LINE INPUT
