Bi-Amping
It is possible to connect speakers supporting bi-amping to improve quality of
the bass and treble. Up to 5.1 ch will be played in bi-amping.
Connections
1. Connect as below using the FRONT terminals and HEIGHT/Bi-AMP
terminals.
2. Turn the unit on and set "Speaker Setup" to "Bi-Amp".
1 After pressing RCV, press HOME on the remote controller.
2 Select "Setup" with the cursors and press ENTER.
3 With the cursors, select "2.Speaker Setup" - "Speaker Settings" -
"Front Speakers Type".
4 Select "Bi-Amp" with the cursors.
Before bi-amping, be sure to remove the short-circuit connector that
connects the tweeter (treble) terminal and the subwoofer (bass)
terminal.
Use speakers supporting bi-amping only. For details, refer to the
speakers' instruction manual.
