Connections
a
SUB Monitor
Be sure to insert the HDMI
cable all the way in.
SUB Monitor
This unit has multiple HDMI OUT jacks, and another TV or projector can be
connected to the HDMI OUT SUB jack.
• Switch between MAIN and SUB using the HDMI MAIN/SUB button on the
remote controller ( →p18) or "Quick Menu" ( →p91). Note that this jack
is not ARC-compatible.
• If devices with di󰀨erent resolutions are connected to HDMI OUT MAIN jack
and SUB jack, images are output with the lower resolution.
Connecting the SUB Monitor
a HDMI cable

Onkyo TX-RZ70 Specifications

General

Type	AV Receiver
Channels	11.2
Power per Channel	140 W (8 ohms, 20 Hz-20 kHz, 0.08% THD, 2 channels driven)
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Dirac Live	Yes
Roon Tested	Yes
Wireless	Yes
THD	0.08%
HDMI Inputs	7
HDMI Outputs	3
Streaming	Spotify, TIDAL, Deezer, TuneIn, Pandora
Power Output	140W per channel (8 ohms, 20Hz-20kHz, 0.08% THD, 2 channels driven)
Frequency Response	5 Hz-100 kHz/+1 dB, -3 dB (Direct Mode)
Input Sensitivity and Impedance	200mV/47k ohms
Signal-to-Noise Ratio	106 dB (Line, IHF-A)
Video Section	4K/120Hz
HDMI Support	eARC, 8K/60 Hz, 4K/120 Hz
Bluetooth	Yes
Wi-Fi	Yes (2.4/5 GHz)
Supported Audio Formats	MP3, WMA, AAC, WAV, FLAC, DSD
Dimensions	435 x 201.5 x 388 mm
