Onkyo TX-SA706

113
Specifications
Amplifier Section
Video Section
Tuner Section (TX-SR706 only)
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
Rated Output Power
All channels: North American:
100 watts minimum continuous
power per channel, 8 ohm loads, 2
channels driven from 20 Hz to 20
kHz, with a maximum total
harmonic distortion of 0.08% (FTC)
115 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.7% (FTC)
125 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.1% (FTC)
European:
7 ch × 160 W at 6 ohms, 1 kHz, 1 ch
driven (IEC)
Others:
7 ch ×160 W at 6 ohms, 1 kHz, 1 ch
driven (IEC)
Maximum Output Power
7 ch × 175 W at 6 ohms, 1 kHz, 1 ch
driven (JEITA)
Dynamic Power 240 W (3 Ω, Front)
210 W (4 Ω, Front)
120 W (8 Ω, Front)
THD (Total Harmonic Distortion)
0.08% (Power Rated)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE)
2.5 mV/47 kΩ, (PHONO MM)
Output Level and Impedance
200 mV/470 Ω (REC OUT)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Frequency Response 5 Hz - 100 kHz/+1 dB - 3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Speaker Impedance 4 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component and S-Video Y)
0.7 Vp-p/75 Ω (Component P B /C B , P R /C R )
0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 50 MHz - 3 dB
FM Tuning Frequency Range
North American:
87.5 MHz - 107.9 MHz
Others: 87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
North American: 530 kHz - 1710 kHz
European: 522 kHz - 1611 kHz
Others: 522/530 kHz - 1611/1710 kHz
Preset Channel 40
Digital Tuner (North American models only):
XM, SIRIUS
Power Supply North American: AC 120 V, 60 Hz
European: AC 220 - 240 V, 50/60 Hz
Others: AC 220 - 240 V, 50/60 Hz
AC 120 V, 60 Hz
Power Consumption North American: 5.9 A
European: 550 W
Others: 550 W
Dimensions (W
× H × D)
435 × 174 × 377 mm
17-1/8" × 6-7/8" × 14-13/16"
Weight North American:12.2 kg (27.0 lbs.)
Others:12.3 kg (27.2 lbs.)
HDMI IN 1, IN 2, IN 3, IN 4
Component IN 1, IN 2
S-Video DVD, VCR/DVR, CBL/SAT, GAME/
TV, AUX
Composite DVD, VCR/DVR, CBL/SAT, GAME/
TV, AUX
HDMI OUT
Component MONITOR OUT
S-Video MONITOR OUT, VCR/DVR OUT
Composite MONITOR OUT, VCR/DVR OUT
Digital Inputs Optical: 2 (Rear), 1 (Front)
Coaxial: 3
Analog Inputs TX-SR706:
DVD (Multichannel), VCR/DVR,
CBL/SAT, GAME/TV, AUX, TAPE,
CD, PHONO
TX-SA706:
DVD (Multichannel), VCR/DVR,
CBL/SAT, GAME/TV, AUX, TAPE,
CD, PHONO, TUNER
Multichannel Inputs 7.1
Analog Outputs TAPE, VCR/DVR, ZONE2, PRE OUT
Multichannel Pre
Outputs 7
Subwoofer Pre Output 1
Speaker Outputs Main (L, R, C, SL, SR, SBL, SBR)
+ ZONE2 (L, R)
Phones 1
MIC Yes
RS232 1
IR Input 1
12 V Trigger Out ZONE2
