Onkyo TX-SA706

26
Connecting the AV Receiver/AV Amplifier—Continued
See “Connecting Components with HDMI” on page 33 for HDMI connection information.
• With connection , you can listen to and record audio from a DVD and listen in Zone 2.
• To enjoy Dolby Digital and DTS, use connection or . (To record or listen in Zone 2 as well, use and ,
or and .)
• If your DVD player has main left and right outputs and multichannel left and right outputs, be sure to use the
main left and right outputs for connection .
Connecting a DVD Player
Connection AV receiver/AV amplifier Signal flow DVD player
COMPONENT VIDEO IN 1 (DVD) ⇐ Component video output
DVD S ⇐ S-Video output
DVD V ⇐ Composite video output
DVD FRONT L/R ⇐ Analog audio L/R output
DIGITAL COAXIAL IN 1 (DVD) ⇐ Digital coaxial output
DIGITAL OPTICAL IN 1 (GAME/TV) ⇐ Digital optical output
Step 1: Video Connection
Choose a video connection that matches your DVD player ( , , or
), and then make the connection.
You must connect the AV receiver/AV amplifier to your TV via the same type of connection.
A B C
Step 2: Audio Connection
Choose an audio connection that matches your DVD player ( , , or ), and then make the connection.
a b c
a
b c a b
a c
a
A
B
C
a
b
c
YCOAXIAL
OUT
PB
COMPONENT VIDEO OUT
P
R S VIDEO
OUT
AUDIO
OUT
VIDEO
OUT
LR
OPTICAL
OUT
b
c
A
B
C
B
a
C
DVD player
To connect a DVD player or DVD-Audio/SACD-capable player with a
multichannel analog audio output, see page 27.
Connect one or the other
Connection must be assigned (see page 44)
c
