Connecting Your Components —Continued
•With connection , you can listen to and record audio from your TV and listen in Zone 2.
•To enjoy Dolby Digital and DTS, use connection or . (For recording, use and , or and .)
Hint!
If your TV has no audio outputs, connect an audio output from your VCR to the AV receiver and use its tuner to lis-
ten to TV programs through the AV receiver.
Connecting a TV or Projector
Connection AV receiver Signal flow TV Picture quality
COMPONENT VIDEO OUT
⇒
Component video input
Best
MONITOR OUT S
⇒
S-Video input Better
MONITOR OUT V
⇒
Composite video input
Standard
VIDEO 3 IN L/R
⇐
Analog audio L/R output
DIGITAL COAXIAL IN 2
⇐
Digital coaxial output
DIGITAL OPTICAL IN 2
⇐
Digital optical output
Step 1: Video Connection
Choose a video connection that matches your TV ( , , or ), and then make the connection.
A B
C
Step 2: Audio Connection
Choose an audio connection that matches your TV ( , , or ), and then make the connection.
a b c
a
b
c
a
b
a c
A
B
C
a
b
c
COAXIAL
IN 2
YCOAXIAL
OUT
PB
COMPONENT VIDEO IN
P
R S VIDEO
IN
AUDIO
OUT
VIDEO
IN
MONITOR
OUT
V
S
MONITOR
OUT
LR
OPTICAL
OUT
OPTICAL
IN 2
Y
P
B
PR
COMPONENT VIDEO
L
R
IN
VIDEO 3
b
c
A
B
C
B
a
C
TV, projector,
etc.
Connect one
or the other
