TX-SR803/TX-SR703

Quick Guide

This guide shows how to get your AV receiver up and running quickly and smoothly. It shows you how to

connect your speakers, DVD player, and TV, and how to use Automatic Speaker Setup. For full details on

using the AV receiver, refer to the main instruction manual.

Home Theater Basics

Front speakers

Center speaker

Subwoofer

Surround

back

speakers

Surround speakers

❍ Where to Put Your Speakers

Connections 1 through 5 are explained on the following pages.

: Signal Flow

Video

Audio

Speakers

DVD player

Audio

❍ Audio & Video Signal Flow

TX-SR803DIG.fm Page 1 Thursday, August 25, 2005 11:48 AM
