Onkyo TX-SR876

1/128 PAGE
TX-SR876/SA876
<Note>
Mechanical parts and pcb ass'y marked by "NSP" are generally unavailable
because they are not in the Master Spare Parts List.
IC chip marked by "NSP" is impossible to remove form pcb, so it is unavailable too.
<Notes>
(B) : TX-SR876 Black model <DC> : TX-SR876 USA and Canadian model
(G) : TX-SR876 Golden model <DD> : TX-SR876 USA model
(S) : TX-SR876 Silver model <DT> : TX-SR876 Asian model for 120V
<SR876> : TX-SR876 All model <MP> :TX-SR876 European model
<SA876> : TX-SA876 Chinese model <MB> : TX-SR876 UK model
<MT> : TX-SR876 Asian model for 220V
EXPLODED VIEW PARTS LIST
REF. NO. PART NAM
E
DESCRIPTION Q'TY PART NO.
(
SN
)
REMARK
S
A001 HEAT SINK 238 2 27160605B
A004 ISO PLT (HS) 1 28175334
A005 SPACER (PC) 8 27270485
A007 SCREW 3P+6FN(3BC) 14 82143006GR
A008 SCREW 3TTB+8B(3CM)SR 83 801637
A009 SCREW 3SMS8W.SW+14B(CU) 28 801634
A011 RETAINER (HS-2) 2 27141530A
A014 SPACER t0.5x8x3.2 3 27270438
A015 CHASSIS (SUB) 1 ---
NSP
A018 CUSHION (T3*W35*D10) 1 28141741
A020 CUSHION t10*10*100 1 28141746
A021 CUSHION (BUTYL) 1 28141748
A022 TAPE TAPE(CLOTH-8U) 6 29110082
A024 CUSHION (BUTYL) 1 28141748
A025 HEAT SINK(S) 240 1 27160608
A030 ISO PLT (AMP2) 1 28175333
A031 RIVET P-RIVET NRP-345 2 880009
A032 CUSHION T5*8*8 2 28141742
A033 ISO PLT (AMP) 1 28175331A
A037 SCREW 3TTB+8B(3BC) 71 838430088GR
<DC, DD>
A037 SCREW 3TTB+8B(3BC) 67 838430088GR
<DT, MT>
A037 SCREW 3TTB+8B(3BC) 68 838430088GR
<MP, MB>
A037 SCREW 3TTB+8B(3BC) 64 838430088GR
<SA876>
A038 ISO PLT (FFC) 1 28175332
A039 PLA RIVET P3035B 2 880016
A040 BRACKET (FAN-L) 1 27131022A
A042 HOLDER (FAN) 4 27191307
A044 BRACKET (FAN-R) 1 27131023A
A046 HOLDER (FAN) 4 27191307
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PAR
T
NUMBER SPECIFIED.
