Onkyo TX-SR876 - Hdmi Pc Board (Nahdm-9114-1 A)

99/128 PAGE
S7650 or PUSH SW NPS-111-S677 ( 1) 25035714T
S9000 P SW NPS-111-L590P 1 25035636
!, <MP, MB, MT, DT, SA876>
U42 HDMI PC BOARD (NAHDM-9114-1A)
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN)
REMARKS
U8001 IC VX-50 1 22242392R3
U8027 IC HY5DU561622ETP-4-C 1 22242450R3
U8027 or IC HY5DU561622FTP-4-C ( 1) 22242577R3
U8028 IC HY5DU561622ETP-4-C 1 22242450R3
U8028 or IC HY5DU561622FTP-4-C ( 1) 22242577R3
U8029 IC HY5DU561622ETP-4-C 1 22242450R3
U8029 or IC HY5DU561622FTP-4-C ( 1) 22242577R3
U8030 IC HY5DU561622ETP-4-C 1 22242450R3
U8030 or IC HY5DU561622FTP-4-C ( 1) 22242577R3
U8031 IC(VIDEO MEMORY) S29GL128N10TFI020(0290) 1 222W0071R30290A
U8031 or IC(VIDEO MEMORY) S29GL128P90TFIR20(0290) ( 1) 222W0090R30290A
U8067 IC LP2996MX 1 22242438R2
Q8101 IC AD8196 1 ---
NSP
Q8102 TR 2SK3019 1 2216520R2
Q8103 TR 2SK3019 1 2216520R2
Q8104 IC SN74CB3T3306DCT 1 22242454R2
Q8105 IC S-24CS02AFT-V-G 1 22242360R2
Q8105 or IC BR24L02FV-W ( 1) 22242069R2
Q8108 TR DTA144EE 1 2216380R2
Q8109 TR DTC144EE 1 2216390R2
Q8124 IC SN74CB3T3306DCT 1 22242454R2
Q8125 IC S-24CS02AFT-V-G 1 22242360R2
Q8125 or IC BR24L02FV-W ( 1) 22242069R2
Q8128 TR DTA144EE 1 2216380R2
Q8129 TR DTC144EE 1 2216390R2
Q8151 IC AD8196 1 ---
NSP
Q8152 TR 2SK3019 1 2216520R2
Q8153 TR 2SK3019 1 2216520R2
Q8154 IC SN74CB3T3306DCT 1 22242454R2
Q8155 IC S-24CS02AFT-V-G 1 22242360R2
Q8155 or IC BR24L02FV-W ( 1) 22242069R2
Q8158 TR DTA144EE 1 2216380R2
Q8159 TR DTC144EE 1 2216390R2
Q8174 IC SN74CB3T3306DCT 1 22242454R2
Q8175 IC S-24CS02AFT-V-G 1 22242360R2
Q8175 or IC BR24L02FV-W ( 1) 22242069R2
Q8178 TR DTA144EE 1 2216380R2
Q8179 TR DTC144EE 1 2216390R2
Q8305 IC S-812C50BUC-C5ET2G 1 22242407R2
Q8306 IC TC7SZ08FU(TE85L_F) 1 22242071R2TO
Q8306 or IC NC7SZ08P5X_F042 ( 1) 22242482R2
Q8309 TR ARRAY UM6K1N 1 226066R2
