Onkyo TX-SR876

6/128 PAGE
Q6090 TR 2SA1962-O 1 2202833
Q6090 or TR 2SA1962-R ( 1) 2202832
Q6091 TR 2SA1962-O 1 2202833
Q6091 or TR 2SA1962-R ( 1) 2202832
Q6092 TR 2SA1962-O 1 2202833
Q6092 or TR 2SA1962-R ( 1) 2202832
Q6093 TR 2SA1962-O 1 2202833
Q6093 or TR 2SA1962-R ( 1) 2202832
Q6094 TR 2SA1962-O 1 2202833
Q6094 or TR 2SA1962-R ( 1) 2202832
Q6095 TR 2SA1962-O 1 2202833
Q6095 or TR 2SA1962-R ( 1) 2202832
Q6096 TR 2SA1962-O 1 2202833
Q6096 or TR 2SA1962-R ( 1) 2202832
<Notes>
When replacing the following the transistors, use ones of the same Hfe rank as the original type.
Ref. No. : Q6050 - 6060, Q6051 - 6061, Q6052 - 6062, Q6053 - 6063, Q6054 - 6064, Q6055 - 6065, Q6056 - 6066
Ref. No. : Q6080 - 6090, Q6081 - 6091, Q6082 - 6092, Q6083 - 6093, Q6084 - 6094, Q6085 - 6095, Q6086 - 6096
T901 P TRANS NPT-1553D 1 2301893
!, <DC, DD, DT>
T901 P TRANS NPT-1553M 1 2301894
!, <MP, MB, MT, SA876>
T903 P TRANS NPT-1555D 1 2301902A
!, <DC, DD>
U01 AMPLIFIER PC board ass'y NAAF-9039-1E* 1
1B170539-1E
U02 POWER SUPPLY PC board ass'y NAPS-9040-1E 1
1B170540-1E
U03 POWER SUPPLY PC board ass'y NAPS-9041-1E 1
1B170541-1E
U04 THERMAL SENSOR PC board ass'y NAETC-9042-1E 1
---
NSP
U05 THERMAL SENSOR PC board ass'y NAETC-9043-1E 1
---
NSP
U06 AMPLIFIER PC board ass'y NAASP-9050-1M* 1
1B170550-1M
<DC, DD, DT, MP, MB, MT>
NAASP-9050-1P* 1
1B170550-1P
<SA876>
U07 PHONO PC board ass'y NAASP-9051-1M 1
1B170551-1M
<DC, DD, DT, MP, MB, MT>
NAASP-9051-1P 1
1B170551-1P
<SA876>
U08 VIDEO PC board ass'y NAVD-9052-1M 1
1B170552-1M
<DC, DD, DT, MP, MB, MT>
NAVD-9052-1P 1
1B170552-1P
<SA876>
U09 CONNECTOR PC board ass'y NAETC-9053-1M 1
---
NSP
NAETC-9053-1P 1
---
NSP
U10 CONNECTOR PC board ass'y NAETC-9054-1M 1
---
NSP
NAETC-9054-1P 1
---
NSP
U11 SP TERMINAL PC board ass'y NATRM-9055-1AA* 1
1B170555-1AA
<DC, DD>
NATRM-9055-1AG* 1
1B170555-1AG
<MB>
NATRM-9055-1C* 1
1B170555-1C
<MP, MT>
NATRM-9055-1D* 1
1B170555-1D
<DT>
NATRM-9055-1X* 1
1B170555-1X
<SA876>
U12 SP TERMINAL PC board ass'y NAETC-9056-1AA 1
1B170556-1AA
<DC, DD>
NAETC-9056-1AG 1
1B170556-1AG
<MB>
NAETC-9056-1C
1
1B170556-1C
<MP, MT>
NAETC-9056-1D 1
1B170556-1D
<DT>
NAETC-9056-1X 1
1B170556-1X
<SA876>
U13
POWER SUPPLY PC board ass'y NAPS-9057-1AA 1
1B170557-1AA
<DC, DD>
NAPS-9057-1AG 1
1B170557-1AG
<MB>
