TERMINAL DESCRIPTION(5/5)
IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS -21
Q3401, Q3501: D790E001BZDH300 (Audio DSP)
TX-SR876/SA876
BALL
SIGNAL NAME TYPE
(1)
PULL
(2)
GPIO
(3)
DESCRIPTION
NO.
McASP0, McASP1, McASP2, and SPI1 Serial Ports
AHCLKR0/AHCLKR1 B3 IO - Y McASP0 and McASP1 Receive Master Clock
ACLKR0 A5 IO - Y McASP0 Receive Bit Clock
AFSR0 B4 IO - Y McASP0 Receive Frame Sync (L/R Clock)
AHCLKX0/AHCLKX2 C2 IO - Y McASP0 and McASP2 Transmit Master Clock
ACLKX0 A4 IO - Y McASP0 Transmit Bit Clock
AFSX0 A3 IO - Y McASP0 Transmit Frame Sync (L/R Clock)
AMUTE0 C1 O - Y McASP0 MUTE Output
AXR0[0] A14 IO - Y McASP0 Serial Data 0
AXR0[1] B13 IO - Y McASP0 Serial Data 1
AXR0[2] A13 IO - Y McASP0 Serial Data 2
AXR0[3] B12 IO - Y McASP0 Serial Data 3
AXR0[4] A12 IO - Y McASP0 Serial Data 4
AXR0[5]/SPI1_SCS
B11 IO - Y McASP0 Serial Data 5 or SPI1 Slave Chip Select
AXR0[6]/SPI1_ENA A11 IO - Y McASP0 Serial Data 6 or SPI1 Enable (Ready)
AXR0[7]/SPI1_CLK B10 IO - Y McASP0 Serial Data 7 or SPI1 Serial Clock
AXR0[8]/AXR1[5]/ McASP0 Serial Data 8 or McASP1 Serial Data 5 or
B9 IO - Y
SPI1_SOMI SPI1 Data Pin Slave Out Master In
AXR0[9]/AXR1[4]/ McASP0 Serial Data 9 or McASP1 Serial Data 4 or
A9 IO - Y
SPI1_SIMO SPI1 Data Pin Slave In Master Out
AXR0[10]/AXR1[3] B8 IO - Y McASP0 Serial Data 10 or McASP1 Serial Data 3
AXR0[11]/AXR1[2] A8 IO - Y McASP0 Serial Data 11 or McASP1 Serial Data 2
AXR0[12]/AXR1[1] B7 IO - Y McASP0 Serial Data 12 or McASP1 Serial Data 1
AXR0[13]/AXR1[0] B6 IO - Y McASP0 Serial Data 13 or McASP1 Serial Data 0
AXR0[14]/AXR2[1] A6 IO - Y McASP0 Serial Data 14 or McASP2 Serial Data 1
AXR0[15]/AXR2[0] B5 IO - Y McASP0 Serial Data 15 or McASP2 Serial Data 0
ACLKR1 E1 IO - Y McASP1 Receive Bit Clock
AFSR1 F1 IO - Y McASP1 Receive Frame Sync (L/R Clock)
AHCLKX1 D1 IO - Y McASP1 Transmit Master Clock
ACLKX1 E2 IO - Y McASP1 Transmit Bit Clock
AFSX1 F2 IO - Y McASP1 Transmit Frame Sync (L/R Clock)
AMUTE1 D2 O - Y McASP1 MUTE Output
AHCLKR2 C14 IO IPD Y McASP2 Receive Master Clock
ACLKR2 C13 IO IPD Y McASP2 Receive Bit Clock
AFSR2 C12 IO IPD Y McASP2 Receive Frame Sync (L/R Clock)
ACLKX2 D11 IO IPD Y McASP2 Transmit Bit Clock
AFSX2 C11 IO IPD Y McASP2 Transmit Frame Sync (L/R Clock)
AMUTE2/HINT
D10 O IPD Y McASP2 MUTE Output or UHPI Host Interrupt
SPI0, I2C0, and I2C1 Serial Port Pins
SPI0_SOMI/I2C0_SDA B14 IO - Y SPI0 Data Pin Slave Out Master In or I2C0 Serial Data
SPI0_SIMO B15 IO - Y SPI0 Data Pin Slave In Master Out
SPI0_CLK/I2C0_SCL C16 IO - Y SPI0 Serial Clock or I2C0 Serial Clock
SPI0_SCS/I2C1_SCL C15 IO - Y SPI0 Slave Chip Select or I2C1 Serial Clock
SPI0_ENA/I2C1_SDA
D16 IO - Y SPI0 Enable (Ready) or I2C1 Serial Data
