4.3.3. Power Supply
Connect the supplied power supply to the Compute Box 24V connector.
Quick Changer 3FG15 HEX-E/H QC RG2/6 RG2-FT Screwdriver VG10/VGC10
1.5 A
5 A
NOTE:
To disconnect the power connector,
make sure to pull the connector housing
(where the arrows are shown) and not
the cable.
CAUTION:
Use only original OnRobot power
supplies.
Finally, power up the power supply that will power the Compute Box and the connected
Tool(s).
HW INSTALLATION
31
