H ea dlamp sy stem
Headlamps with separate systems
for low beam 1 (outer bulbs) and
high beam 2 (inner bulbs).
Low be am
1. Open bonnet and remove 3 screw s from
headlamp protective cover.
2. Rotate bulb socket a nti-clockwise and
pull it out of head lamp assembly.
3. Deta ch p lug connector from bulb socket.
4. Remove bulb from bulb socket and insert
new bulb, without touching the glass.
5. Attach plug connector to b ulb socket,
push bulb socket into headlamp
assembly and rotate bulb sock et
clockwise.
6. Replace headlam p protective cover,
rep lace 3 screws to hold cover in place
and close bonnet.
High beam
1. Open bonnet and remove headlamp
protective cover.
2. Rotate bulb socket anti-clockwise and
pull it out of headlamp assembly.
3. Detach plug connector from b ulb socket.
4. Remove bulb from bulb socket and insert
new bulb, without touching the g la ss.
5. Attach plug connector to bulb socket,
push bulb socket into headlamp
assembly and rotate bulb socket
clockwise.
6. Replac e head lamp protective cover and
close bonnet.
