Thermocode 2 Printer manual Version 2.04 January 2011 50
50
53CR MAGAZINE SPARES
SPR 761152 (Spring Rewind)
ROD 761142 (Rod Foil)
ROD 761142 (Rod Foil)
ASY 761106 (Assembly Roller)
WAS 751011 (Washer)
STU 761025 (Stub)
SPR 530001 (Spring Clip)
WAS 751031 (Washer)
M3 CAP SCREW x 8mm
SCR 256 x 1/8" (Pan Head Screw)
DIS 761019 (Disc Foil)
ASY 761110 (Assy Feed Spool)
SOC 761117 (Socket location)
M3 NUT (Hexagon Nut)
STU 761025 (Stub)
ASY 761106 (Assembly Roller)
WAS 751011 (Washer)
Socket Set Screw M3 x 16
BEL 761154 (Belt Brake)
ASY 761127 (Drive Roller)
SPR 761153 (Spring Foil Tension)
SPR 761022 (Spring Brake)
SOC 761117 (Socket location)
ROD 761142 (Rod Foil)
ROD 761142 (Rod Foil)
ASY 761106 (Assembly Roller)
WAS 751011 (Washer)
STU 761070 (Stub)
SPR 761098 (Spring Nip Roller)
SLE 761032 (Sleeve Spring Location)
ASY 761008 (Assy Nip Roller)
PLA 761172 (Plate Cassette)
ASY 761108 (Assy Rewind Spool)
BEL 761089 (Belt Takeup)
To Next Page
