Error Codes
Error
Number
Error
Message
Reason Corrective Measures
23
Serial port
overrun
Problem of serial port
handshake.
Check your Com Port Setting. Try new serial port
cable. If this makes no difference change the
Processor Boards.
24
Serial buffer
overrun
Problem of serial port
handshake.
Check your Com Port Setting. Try new serial port
cable. If that makes no difference change the
Processor Boards.
25
Start sensor too
close.
The start sensor is to close to
the Print head
Move the start sensor way from the Print head.
26
Sys param
unknown
Requested or sent a
unknown System Variable
Request or send the correct one.
27
Relay delay out
of range
Problem with variable
SYSRELDEL
Check the setting in the Mini Terminal. Service
menu no 6, menu no 3 Delay (Inhib delay)
28
Format param
unknown
Format Parameters
incorrectly entered in the
format.
Correct the Parameters. The fault can only be
created using Dos.
29
Sys string long
System Variable string has
an incorrect entry.
.i.e. 13 months instead of 12
entered in SYSMON etc.
Correct the System Variable and resend to the
Printer.
30
List type
unknown
Z
?
Requesting a nonexistent
system variable
Clear the error. Enter the correct request code.
31
Delete type
unknown
Deleting an Unknown
request.
Incorrect escape code used when using the delete
command.
32
List file
unknown
Requesting a non existent
Format Font etc.
Clear the error. Request the correct Format or Font
etc.
33
Delete file
unknown
Deleting an Unknown Format
File.
Typing error or the Format, Font etc is not in the
Printer.
34
Bad line
1. Communication Lead
faulty.
2. Codesoft has been
Networked
1. Check the communications lead is plugged in on
the Computer & Printer. Check the lead for any
dry joints.
2. If not Networked, check Codesoft is not set
on Network in the Advanced menu.
35
Bad Format
Line
Format information Incorrect Correct the format design.
36
Format line too
long
1.Text line too long maximum
of 149 character & spaces.
2. The text box used in
Codesoft is larger than the
required text. With no
carriage return.
3. Codesoft, Word wrap has
been checked.
4. Baud rate incorrect
1. Reduce the text line.
2. Reduce the text box to the size of the text
length.
3. Uncheck the word wrap in Properties &
Paragraph.
4.Check the Baud rate with in Codesoft.
37
Local graphic
error
Problem with local graphic in
a format.
Re-load format, or check graphic.
38
Graphic file
missing
Format sent to the Printer
with out the Graphic File.
Global graphic has been
deleted from the Printer.
In Codesoft Printer settings, General, Reload
image at next print job should be checked. (Box
ticked)
Correct the Format Design & resend to the printer.
39
Too many local
graphics
Too many local graphics
designed with in the Format.
Reduce the number of graphics with in the Format
design.
40
Too many
graphics
Too many local and global
graphics loaded to the Printer
Reduce the number global graphics.
41
Cant update
format not
selected
The Format has not been
selected for Printing.
Select the format you wish to send Modified data
only to.
42
Box to narrow
for line width
Box design incorrect
Correct the Format design. The fault can only be
created in Dos.
43
Box to low for
line height
Box design incorrect
Correct the Format design. The fault can only be
created in Dos.
Note-:
The first
error shown with in the Mini Terminal is the fault. Any other error faults shown on the
display, maybe generated because of this fault shown
.
