Thermocode 2 Printer manual Version 2.04 January 2011 43
Error Codes
Error
Number
Error Message Reason Corrective Measures
43
44
Line/ box too
wide
Box design incorrect
Correct the Format design. The fault can only be
created in Dos.
45
Rotation out of
range
Incorrect Rotation set in the
Format should be 0,1,2 or 3
Correct the Format with correct rotation. The fault
can only be created using Dos.
46
Scale factor
wrong
Graphic Scaling factor
incorrect should be 0,1 or 2
Correct the Format design.
47
Bar lines
overflow
Incorrect barcode design.
Correct the barcode design. The fault can only be
created in Dos.
48
Bad bar style
Selected a non-supported
Barcode type.
Check the type of Barcode required. The fault can
only be created in Dos.
49
Bad bar width
Bar width larger than 5 or
less than 2.
Bar width Maximum 5, Minimum 2. The fault can
only be created in Dos.
50
Bad bar ratio
Ratio within the Barcode
Format design incorrect.
Available Ratios are 0 =3,1=
2.5 & 2= 2
Correct the Format design. The fault can only be
created in Dos.
51
Bad bar human
Human readable is larger
than 1
Human readable maximum 1 Minimum 0. The fault
can only be created in Dos.
52
Bad bar csum
Check Digit value larger than
1
Check digit Maximum 1, Minimum 0. The fault can
only be created in Dos.
53
Bad bar speed
Incorrect Speed flag. Should
be Zero
Correct the Barcode design. The fault can only be
created in Dos.
54
Bad bar data
Barcode data to many or few
digits for the barcode type.
Check Type of Barcode,
whether numerical or
Alphabetical or both.
Change the number of digits to suit the Barcode
type, check the style of barcode and the data
needed.
55
Graphic To
Wide
Graphic to wide for the
printer. Graphic file
corrupted?
Resize or replace the graphic
56
X underflow
Format design is out side the
Print area, on the left side of
the
“X”
axis.
Move the Format design to be with in the Print
area.
57
X overflow
Format design is out side the
Print area, on the right side of
the
“X”
axis.
Move the Format design to be with in the Print
area.
58
Y underflow
Format design is out side the
Print area, at the top of the
page on the
“Y”
axis.
Move the Format design to be with in the Print
area.
59
Y overflow
Format design is out side the
Print area, at the bottom of
the page on the
“Y”
axis.
Move the Format design to be with in the Print
area.
60
Timeout in
Binary
1. Incorrect Baud Rate Set
2. Noise on the
Communication lead
3. Incorrect Network number
set. (Network printers only)
1. Check the Baud Rate
2. Check the communication lead.
3. Check the Network number.
61
Timeout in
format
1. Information in the Format
Design, missing or
incorrect
2. Network number set in the
Printer. But not in
Codesoft.
1. Correct the Format Design. Other error
generated
during the download of the format or fonts.
2. Set the Printer Network number to Zero if no
Network. Then re-boot the Printer.
If networked, set network number in Codesoft.
Note: -
Note: -
X and Y overflows. Do not use Arial Black type font. The Codesoft WYSIWYG is incorrect
when using this Font.
The first
error shown with in the Mini Terminal is the fault. Any other error faults shown on
the display, maybe generated because of this fault shown
.
