Thermocode 2 Printer manual Version 2.04 January 2011 44
44
Error
Number
Error Message Reason Corrective Measures
Error Codes
Note-:
The first
error shown with in the Mini Terminal is the fault. Any other error faults
shown on the display, maybe generated because of this fault shown
.
62
Format not
found
Requested a Format not
downloaded to the Printer.
Requested the wrong Format name or the
Format is not Loaded to the Printer.
63
Erasing font in
use
Deleting a Font when used in
the current format.
Stop Printing, delete the Font. Re-select a
format.
64
Reverse field
wrong
Reverse image text should
be 0 or 1 (not supported)
Correct the field.
65
Proportional
field wrong
Incorrect Proportional field.
Value = 0 or 1
Correct the value. The fault can only be created
in Dos.
66
Text field
overflow
Maximum Text in variable =
0 to 59
Reduce text length in variable to less than 60.
67
Text lines
overflow
Too many text lines with in
the designed format
Reduce the amount of Text. Maximum of 120
lines.
68
Text fields
overflow
Too many text fields in the
format.
Reduce text fields in format to be below 150.
69
Too many
counters
Format design has too many
counters maximum of 20
counter fields.
Reduce the number of counter fields with in the
Format design.
70
Too many
Variable
Too many variable with in the
format.
Reduce the number of variables.
71
Missing
Variable
The variable has not loaded
with the format
Correct the format design
72
Variable out of
Limit
Variable field with high and
low limits
Correct the variable field. The fault can only be
created in Dos.
73
Global counter
too wide for
field
Incorrect counter field design
Correct the counter field. Enter a Padding
Character in the Counter Field.
Found in “Output” Enter “0” (Zero).
74
Local counter
too wide for
field
Incorrect counter field design
Correct the counter field. Enter a Padding
Character in the Counter Field.
Found in “Output” Enter “0” (Zero).
75
Font missing
The Font required is not
loaded to the Printer
Load the appropriate Font to the Printer.
76
Font size
unavailable
A Bit Map Font (SFP) has
been down loaded.
The Format design has an
incorrect point size.
Correct the Format design. Or load the Bit Map
font required.
77
Font file
problem
Bit map font loaded to the
Printer with out a font size.
Delete the font, correct your font file then reload
the font to the Printer. Enter the font size The
fault can only be created using Dos File to
download fonts.
78
Font code
problem
Corrupted Font File. Delete and then replace the corrupted Font.
79
Time out of
range
Incorrect time form sent to
the Printer.
e.g. 2530
Correct the field.
80
Date out of
range
Incorrect date form sent to
the Printer.
e.g. 321002
Correct the field.
81
Can’t update
variable
Variable has not been
designed in the format or is
missing.
Correct the format Design.
82
Global variable
unknown
The Global variable has not
been loaded to the Printer.
Or has been deleted.
Resend the Global variable to the Printer.
83
Daysave error
Incorrect information entered
in the daylight save field.
Correct the Daylight saving field.
84
Sys param out
of range
Changing a System
Parameter with a value out
range.
Correct the parameters with in your format
design
The fault can only be created using Termode or
Service.
85
Too Many
Horizontal
Steps
1. The Home offset set too
high for the size of Printer.
2. The Printer has not seen
the End or has sensor failed.
The one to the right of the
Printer.
1. Reduce the Home offset.
2. Check the sensor is clean & working. The
ribbon cables are not fouling the guard of the
Printer. Top line may read as a 107S when the
Printer is a 107M.
