Open Technologies S.r.l.
11. MACHINE SPECIFICATIONS
1.12. DETAILED DESCRIPTION OF THE MACHINE
The 3D scanner has a solid external structure. All the panels are integral part of the tool and must not be re-
moved or tampered with in any way so not to compromise the correct functioning of the apparatus.
On the back of the scanner there is the port for the electrical connection and the power switch of the machine;
another switch is available on the front of the scanner and allows completely switching on the apparatus. In the
frontal part of the scanner can be found the scanning area framed by the optical head and the central clasp that
allows inserting the accessories described in chapter 7.
The optical head lodges the opto-electronic components for the acquisition of the object surface.
NeWay’s Optical Head comprises two video cameras and a DMD projector. The set up of these three compo-
nents allows one single scanning field.
Any other application not present here has not been contemplated by the manufac-
turer and, therefore, cannot be performed.
1.13. REPAIRS AND/OR SAFETY DEVICES DESCRIPTION
The 3D scanner is fitted with external metal panels, which keep electrical parts (feeders) out of reach.
The electrical motor for the rotating table and the projector work on low voltage (12V).
The manufacturer declines any responsibility arising from accidents deriving from
partial or total removal of the protective panels.
1.14. UNAUTHORIZED USES OF THE MACHINE
Using the 3D scanner with damaged wires or plugs
Using the 3D scanner with open or removed panels
Do not expose the 3D scanner to the rain nor place it in places where water is present
(bathtub, basin, sink or washtub, wet floor, near a swimming pool or any similar situa-
tions).
1.15. INDICATIONS ON NOISE EMISSIONS
The noise the machine produces, intended as the level of sound pressure in the workplace, is <80 dB (A).
1.16. INDICATIONS ON VIBRATIONS, RADIATIONS AND FINE PARTICLES
EMITTED BY THE MACHINE
The unit does not emit any vibrations, fine particles or radiation when operating.
1.17. INDICATIONS ON GASSES AND FUMES EMITTED BY THE MACHINE
The unit does not emit any gasses and fumes when operating.
1.18. ELECTRIC SYSTEM INFORMATION
See electrical diagram attached.
Edit N°: 00 - Rev. N°: 01 of 07/17/17 USE INSTRUCTIONS MANUAL
Nome file: NeWay User Manual 2017 rev01.odt Pag. 17 di 26
