1.24. INSTRUCTIONS FOR THE IDENTIFICATION AND LOCALIZATION OF
MALFUNCTIONS DAMAGE AND RE-INSTALLATION AFTER REPAIR
Tabella 2 Trouble Shooting
MALFUNCTION CAUSE SOLUTION
The scanner does not start No power. Check cable connections.
The machine is off.
Make sure the switch on the back
is lit and that the scanner is on.
No image reception on the personal
computer.
Video cable not connected
correctly.
Make sure the video connection
cable (HDMI) is properly con-
nected to the right port on the 3D
scanner and on the personal com-
puter.
USB cables incorrectly connected.
Make sure the USB connection ca-
bles are both properly connected
to the ports on the 3D scanner and
on the personal computer.
Damaged video cable.
Replace the video connection ca-
ble (HDMI).
(1)
Noise Worn electromotor Repair or replace
(1)
Projector out of order Check the projector
(1)
Electrocution when touching the
metal structure of the machine.
Damaged, worn cables in contact
with the metal parts.
Check the wiring of the electric
supply
(1)
The motor does not turn Cable incorrectly connected.
Check the white USB cable con-
nections.
Feeder out of order. Check feeder
(1)
Feeder cable breaking. Replace cable
(1)
1.25. INSTRUCTIONS ON THE USE OF PERSONAL PROTECTION DEVICES
The personal protection means to use are:
 Split leather gloves for lifting and moving.
Please remember that the individual protection device (IPD) the operators use must have EC marking and refer-
ence to the UNI law.
1.26. INSTRUCTIONS ON REQUIRED TRAINING
Scanning must be performed by personnel that have received specific training for the correct operation of this
machine.
The training of the operators should, at least, cover the following topics:
- Operation and general knowledge of the mechanical, electric, electronic parts;
- Information on manual handling;
- information on commands (scanning software);
- Information on safety provisions, specific risks, the use of command devices, forbidden behavior, advis-
able behavior, etc;
