OpenVox WGW1002G - Advanced Routing Patterns

GSM/3G User Manual
55 | 82
Table5-1 Definition of Routing Options
Options
Definition
Routing Name
 The name of this route. Should be used to describe what
types of calls this route matches (for example, 'SIP2GSM' or
'GSM2SIP').
Call Comes in From
 The launching point of incoming calls.
Send Call Through
The destination to receive the incoming calls.
Table5-2 Description of Advanced Routing Rule
Options
Definition
Dial Patterns that will
use this Route
 A Dial Pattern is a unique set of digits that will select this
route and send the call to the designated trunks. If a dialed
pattern matches this route, no subsequent routes will be tried.
If Time Groups are enabled, subsequent routes will be
checked for matches outside of the designated time(s).
Rules:
X matches any digit from 0-9
Z matches any digit from 1-9
N matches any digit from 2-9
[1237-9] matches any digit in the brackets (example:
1,2,3,7,8,9)
. wildcard: matches one or more dialed digits.
prepend: Digits to prepend to a successful match
If the dialed number matches the patterns specified by the
subsequent columns, then this will be prepended before
sending to the trunks
prefix: Prefix to remove on a successful match
The dialed number is compared to this and the subsequent
columns for a match. Upon a match, this prefix is removed
from the dialed number before sending it to the trunks.
match pattern: The dialed number will be compared against
the prefix + this match pattern. Upon a match, the match
pattern portion of the dialed number will be sent to the trunks
CallerID: If CallerID is supplied, the dialed number will only
match the prefix + match pattern if the CallerID has been
transmitted matches this.
When extensions make outbound calls, the CallerID will be
their extension number and NOT their Outbound CID.
